EN 10305-1 E195 is the lowest strength precision tube in the EN 10305-1 precision tube series, with a normalized yield strength of 195 MPa and a carbon content of a maximum of 0.06%. E195 tubes are cold-drawn to close OD and wall thickness tolerances, providing consistent dimensions and tight tolerances in light-duty hydraulic lines, automotive sub-frames, and other general mechanical assemblies that will require forming, bending or flaring after delivery. E195 is supplied in +A (annealed) or +N (normalized) condition to ensure maximum ductility for tubes that require processing at the customer's facility to achieve minimum springback and consistent weld quality with no preheat required. These tubes are usually found in automobiles, industrial equipment, furniture, material-moving machinery and engineering systems where they are required for strength, durability, and resistance to wear under severe operating conditions. We at usapipingsolution provide Mechanical Steel Tubes according to the ASTM A513 standard in a variety of sizes and specifications to fulfill various industrial uses and international quality standards.
Specifications of ASTM A513 Mechanical Steel Tubes (ERW / Welded)
| Specification Attribute | Details for ASTM A513 1010 Tubes & Pipes |
|---|---|
| Primary Standard | ASTM A513 / A513M - Standard Specification for Electric-Resistance-Welded Carbon and Alloy Steel Mechanical Tubing. (Also reference ASME SA513 1010 where equivalent) |
| Type & Grade | Type 1 (Hot-Rolled Strip, Cold-Rolled Strip), Type 5 (Mandrel Drawn), Type 6 (Special Smooth ID). Grade 1010. Type 1A & 1B are common. |
| UNS Designation | UNS G10100 |
| Manufacturing Process | Electric-Resistance-Welded (ERW) |
| Outer Diameter (OD) | Wide range available, typically from 1/2” (12.7 mm) up to 12” (304.8 mm) or more, depending on type and capabilities. |
| Wall Thickness (WT) | Various gauges and wall thicknesses available, typically from 0.028” (0.71 mm) up to 0.500” (12.7 mm) or more. |
| Shapes | Round, Square, Rectangular, Oval, and other special shapes as per ASTM A513. |
| Length | Standard mill lengths (e.g., 20 ft, 24 ft) and custom cut-to-length services. |
| Heat Treatment | Typically supplied in the as-welded or normalized condition. Stress relief annealing or other heat treatments may be applied if required for specific properties. |
| Testing & Certification | Dimensional checks, mechanical tests (tensile, flattening, flaring as per A513), chemical analysis. Mill Test Certificate (MTC) typically provided upon request. |
Equivalent Grades of ASTM A513 Mechanical Steel Tubes (ERW / Welded)
| DIN | EN | BS | NFA | ASTM | ASME |
|---|---|---|---|---|---|
| DIN 17210 Grade Ck10 | EN C10E Grade 10084 | — | ASTM A513 Grade MT1010 | ASME SA 513 Grade MT 1010 | UNI C 10 |
Size Chart of ASTM A513 Mechanical Steel Tubes (ERW / Welded)
| ASTM Standard | Manufacturing Method | Outer Diameter (OD) | Wall Thickness (t) |
|---|---|---|---|
| ASTM A513 | Electric-Resistance-Welded (ERW) Tubing from Hot-Rolled Steel | 12.7–380 mm (1/2–15 in) | 1.65–16.5 mm (0.065–0.65 in) |
| ASTM A513 | Electric-Resistance-Welded (ERW) Tubing from Cold-Rolled Steel | 9.5–300 mm (3/8–12 in) | 0.56–3.4 mm (0.022–0.134 in) |
Comparison between ASTM A513 vs A500 vs A519
| Specification | Manufacturing Type | Primary Applications | Key Strengths & Features | Notable Shapes / Types | Critical Limitation / Consideration |
|---|---|---|---|---|---|
| ASTM A513 | ERW Welded | Mechanical / industrial applications | Tight Outer Diameter (OD) tolerances | Types 1, 2, 5, and 6 | Not suitable for structural columns |
| ASTM A500 | ERW / DOM Welded | Structural applications | Higher yield grades | Round, square, and rectangular | Not intended for precision machining |
| ASTM A519 | Seamless | Mechanical applications | High-tolerance ID and OD; Pressure-capable | Custom / standard seamless profiles | Higher cost than ASTM A513 ERW |
ASTM A513 Wall Thickness Tolerance Chart
| Table Number | Tubing Type & Processing Condition | Measurement Units |
|---|---|---|
| Table 6 | Type 1 (A.W.H.R. – As-Welded Hot-Rolled) Round Tubing | Inch Units |
| Table 7 | Type 1 (A.W.H.R. – As-Welded Hot-Rolled) Round Tubing | SI (Metric) Units |
| Table 8 | Types 5 & 6 (DOM – Drawn Over Mandrel / S.S.I.D. – Special Smooth ID) Round Tubing | Inch Units |
| Table 9 | Types 5 & 6 (DOM – Drawn Over Mandrel / S.S.I.D. – Special Smooth ID) Round Tubing | SI (Metric) Units |
| Table 11 | Type 2 (A.W.C.R. – As-Welded Cold-Rolled) Round Tubing | Inch Units |
| Table 12 | Type 2 (A.W.C.R. – As-Welded Cold-Rolled) Round Tubing | SI (Metric) Units |
Need ASTM A513 Mechanical Steel Tubes?
Get competitive pricing, mill test certificates, and a fast 24-hour quotation turnaround. ERW Types 1, 2, 5 (DOM) & 6 — carbon and alloy grades available.
Applications Uses of ASTM A513 Mechanical Steel Tubes (ERW / Welded)
Frequently Asked Questions
What is ASTM A513 mechanical steel tubing?
ASTM A513 is an electric resistance welded (ERW) carbon steel tubing specification designed for mechanical and structural applications requiring precise dimensions and good surface finish.
What is ASTM A513 used for?
ASTM A513 tubing is commonly used in automotive components, furniture, agricultural equipment, industrial machinery, material handling systems, and general fabrication projects.
What is the difference between ASTM A513 and ASTM A500?
ASTM A513 is primarily intended for mechanical applications with tighter dimensional tolerances, while ASTM A500 is designed for structural applications requiring higher load-bearing capacity.
Is ASTM A513 tubing welded or seamless?
ASTM A513 covers electric resistance welded (ERW) tubing. It is a welded tube specification and does not include seamless tubing.
What are the grades of ASTM A513 tubing?
ASTM A513 includes several grades and types, with common mechanical tubing grades such as MT 1010, MT 1015, MT 1020, and other carbon steel grades selected based on strength and application requirements.
Mill-certified stock. ERW Type 1, 2, 5 (DOM) & 6. Grades MT 1010 – MT 1020. Full MTC documentation.
Send your specification to USA Piping Solution for a same-day quote with confirmed lead times.
